Palladium 10 Gramm per Liter

Anode pad / tampon / anode sleeve / fuzzy sleeve / replacement fabric pad puffy from Betzmann Galvanik.    This puffy fabric pad / anode sleeve or also called tampon is absolutely recommended for all plating processes. Optimally suitable for all coatings and electrolytes.  The coating of larger areas is also quite fast with this pad.   The insertion hole is larger than the electrode and therefore it happens that the moist  anode pad slips off. Therefore, fix the pad on the electrode with a small rubber band.

Our copper electrolyte alkaline for acid-sensitive metals is cyanide-free! Ideal for bath and tampon - / pin electroplating suitable 50 grams copper / liter For use on iron and zinc metals Easy to use and cyanide free   Ideally suited to copperplate even acid-sensitive materials (iron, zinc or steel). For example, copper plating can also be applied to materials that are attacked by the acidic copper electrolyte - for example, rusting steels or other ferrous materials. Copper plating effectively protects workpieces made of iron and steel against rust and gives them an attractive surface thanks to the typical red luster of the precious metal. Because of its good solderability, electroplated copper plating is ideal for the production of printed circuit boards or similar. Simply use the copper electrolyte together with a copper sheet as anode and you can quickly provide a component with a shiny copper coating yourself. The exact instructions for use can be found in our guide here in the download area! For copper plating of non-acid sensitive materials please use the Betzmann Electroplating Bright Copper Electrolyte.  Alkaline copper electrolyte can be used in bath electroplating as well as in pin electroplating/tampon electroplating. Since it enables electroplating of acid-sensitive metals, it is suitable for many applications. Important properties of alkaline copper electrolyte are excellent leveling and good scattering. This color tone can be further enhanced by an additional coating with our bright copper electrolyte. Applications for Copper Electrolyte Alkaline Copper Alkaline prepares acid-sensitive materials for copper plating with acidic copper electrolyte. These include, for example, various ferrous materials or zinc. A particular advantage is that it does not deposit electrolessly on iron, which would form a loose coating before electrodeposition begins. This increases adhesion to ferrous materials. Basic copper electrolyte serves as an intermediate layer for acid-sensitive metals before final plating with acid electrolytic copper or other coatings. Basic copper electrolyte is suitable for the following metals:   Lead, bronze, iron, copper, brass, zinc, tin, steel, zinc die casting and many others. Basic copper is not suitable for aluminum, chromium and titanium. Aluminum requires pretreatment with aluminum activator Please test all other metals not mentioned above for their suitability for electroplating before copper plating.  Application instructions for copper electrolyte alkaline Copper Electrolyte Alkaline is suitable for all electroplating processes from bath electroplating to pin electroplating / pad electroplating. It already works at room temperature; however, it can be heated if necessary. The ideal temperature range is between 25 - 50°C. Clean the workpiece thoroughly before treatment. Please remove dirt and rust with appropriate tools.  Handle the object only with disposable gloves to avoid transferring skin grease to the surface.  Parameters for the use of copper electrolyte alkaline Copper anodes are optimal, nickel or tin anodes are also suitable. Anode on positive pole - Workpiece on negative pole   Recommended electrode: Copper.   Operating Conditions and Deposit Data Voltage Range 4 volts Temperature Above 15 °C Copper Concentration 36 g/l Electrode Copper, Carbon or Platinum(see notes) Copper content in plate 99.8% Plating Rate at (3.5 volts, Platinum electrode) 2 microns per minute (spot) Hardness 370 Hv Density of deposit 8.9 g/cm3 Stress Low – medium stress Special storage requirements None Shelf life 1 – 2 years Health and Safety classification Irritant Special considerations None Transport (UN number) None: Not classified as dangerous for transport  Notes:   We strongly advise against the use of stainless steel anodes for most of our plating processes Plating rates are calculated over a sample area which is permanently covered by swab. Copper electrolyte alkaline / basic for acid sensitive materials The copper gives a beautiful shiny finish. It can still be used with our Bronze- Mixer can be used to mix different color shades from red gloss to white bronze to be able. White bronze is increasingly desired and used as a nickel substitute.   Copper electrolyte alkaline for acid sensitive metals Copper electrolyte alkaline (basic) can be used in both bath electroplating and pen plating / tampon plating. Our alkaline copper electrolyte contains no cyanides. Since it enables electroplating of acid-sensitive metals, it is suitable for many applications. The important properties of alkaline copper electrolyte are excellent levelling and good dispersion. In addition, alkaline or basic copper impresses with an intensive and visually attractive color tone. An additional coating with our bright copper electrolyte can further enhance this color tone. Application areas for copper electrolyte alkaline Copper alkaline prepares acid-sensitive materials for copper plating with acid copper electrolyte. These include various ferrous materials or zinc. A particular advantage is that it does not deposit on iron without current, which would form a loose coating before galvanic deposition begins. This increases the adhesion on ferrous materials. Basic copper electrolyte serves as an intermediate layer for acid-sensitive metals before the final coating with acid electrolytic copper or other coatings. Basic copper electrolyte is suitable for the following metals: Lead, bronze, iron, copper, brass, zinc, tin, steel, zinc die-cast and many others Basic copper is not suitable for aluminum, chrome and titanium. Aluminium requires a pretreatment with the aluminium activator Please test all other metals not mentioned above for their suitability for galvanic copper plating before copper plating Application notes for copper electrolyte alkaline Copper electrolyte alkaline is suitable for all electroplating processes from bath plating to pen plating / pad plating. It already works at room temperature; however, it can be heated up if required. The ideal temperature range is between 25 - 50°C. Clean the workpiece thoroughly before treatment to remove grease and oil. Please remove dirt and rust with appropriate tools. Handle the object with disposable gloves only to avoid transferring skin grease to the surface. Parameters for the use of copper electrolyte alkaline Anodes made of copper are optimal, nickel or tin anodes are also suitable. Anode on positive pole - workpiece on negative pole           Always use gloves and protective goggles and do not inhale the vapors / aerosols. Use only in well ventilated areas!       Identification of the mixture:   Copper electrolyte alkaline (contains copper sulfate, potassium hydroxide)   GHS05 GHS09 GHS07 Signal word: Danger H-phrases: H314: Causes severe skin burns and eye damage. H411: Toxic to aquatic life with long lasting effects. P phrases: P102: Keep out of the reach of children. P280: Wear protective gloves / clothing / eye protection. P301 + P330 + P331: IN CASE OF INSPECTION: Rinse out mouth. Do NOT induce vomiting. P303 + P361 + P353: IF ON SKIN (or hair): Remove all contaminated clothing immediately. Wash skin with water/shower. P305 + P351 + P338: IF IN EYES: Rinse cautiously with water for several minutes. Remove existing contact lenses if possible. Continue to rinse. P501: Dispose of contents/container to hazardous waste.

BMG-25A - Betzmann-Galvanik - Electroplating plant complete basic equipment with electrolytes and gold     Herewith you achieve absolutely perfect results! No matter what size, whether 10 meters of railing or a 28 inch rim, this machine can coat any surface. With 100 ml electrolyte you usually manage 1m2, so it is quite productive!   With this electroplating unit you can easily coat all metallic surfaces and objects made of e.g. tin, zinc, brass, copper, nickel, silver and stainless steel and chrome-plated surfaces or chrome-plated plastic (conductive layer) with all metals available on the market. e.g. real gold (999 fine gold) - rose gold, white gold, antique gold - silver - nickel - alkaline or acid copper - chrome - black chrome - rhodium - black rhodium - palladium - platinum - zinc, tin - bronze - in other words everything we have on stock according to our price list.   Scope of delivery:   1x Electroplating unit 25 A digital, adjustable 2.5 to 15 Volt, analogue or digital depending on availability, mains cable,  1x cable PLUS  1x cable MINUS with clamp 1x handle 3x stainless steel electrodes thick 6mm 1x stainless steel electrode thin 4mm  6x fabric pads mixed 6x cups with lid, scaled  100 ml gold electrolyte 8 G./L. is sufficient for 1m2 surface 100 ml nickel   250 ml chrome remover for dechroming  250 ml Electrocleaner for degreasing  250 ml activator for nickel layer    Manual in German or English as PDF, training films, guides as PDF /EMAIL Personal technical support free of charge, 12 months warranty, free personal instruction and support, unlimited and free advice from our team   Immediately ready for gilding! Can be supplemented with chrome - black rhodium - silver and much more.    High Power 25 Amp switch mode power supply with two digital measuring instruments for output voltage and output current -        Technical data    Operating voltage 230 Volt-AC/ 50Hz Output voltage 3-15 Volt DC adjustable or 13,8 Volt DC fixed voltage by fixed voltage switch on the bottom side Output current 25 amps constant 25 amperes short-term Ripple & Noise <50mV load regulation <200mV line regulation <50mV Displays & movements Analogue meter for voltage and current, status Bi-colour LED red ( fault ) and green DC connection sockets screwable pole terminals Cooling Fan Security Protection against overload, overheating, short-circuit and reverse polarity protection, output voltage protection from 16.5 volts Extras dark grey metal housing with rubber feet, high efficiency > 78% by PFC (Dynamic Power Factor Correction) >0.95 maximizes the required current, high RFI stability Dimensions(WxHxD) 220x110x300 mm Weight 3.5 kg

Galvanic Nickel Electrolyte from Betzmann Galvanik for self-nickel plating Nickel Plating Solution   Our absolutely high-quality galvanic nickel electrolyte has been specially developed for self-nickel plating and may be sold to private individuals without an end-use declaration.   Depending on the material of the workpiece as well as the detailed procedure of nickel plating you will achieve the following results: reliable corrosion protection by a layer combination such as copper-nickel chemically resistant protective layer against diluted acids, alkalis as well as air and water diffusion protection for subsequent electroplating (e.g. diffusion from a base copper layer into the covering gold layer) decorative protective coating with a high-gloss surface, which also serves as wear protection. As an electroplating nickel electrolyte, our product is suitable for bath electroplating as well as for pin electroplating and pad electroplating. During nickel plating, the magnetic properties of the workpiece are retained and it exhibits a high-gloss silver-like color with a subtle yellow tint. Just as convincing as the final result is the high deposition rate exhibited by the nickel electrolyte. Electroplated nickel - decorative or protective coating   If a simply formed workpiece or component is to be provided with a protective layer, we recommend the combination of copper and nickel. In this way, you immediately achieve reliable corrosion protection, which you would otherwise only achieve with pure nickel plating with a layer thickness of 25 to 50 µm. Only at these thicknesses does the coating have the required freedom from pores, since nickel electrolytes always deposit with fine pores. However, electroplated nickel not only protects against corrosion. The coating, which is uncomplicated to apply, is highly resistant to dilute acids and alkalis and serves as wear protection. If several electroplating steps with layers of different metals are planned, an electroplated nickel electrolyte can be used as a barrier layer. In this way, you prevent diffusion or color mixing of different layers. In all processes, it is irrelevant whether you use our nickel electrolyte for bath electroplating or for pin electroplating and pad electroplating. For decorative plating, the combination of bright nickel and chrome is ideal for reliably achieving flat surfaces, although pure bright nickel plating may be sufficient depending on the application.   Application instructions for Betzmann Galvanik's Free Nickel Nickel Electrolyte (bright nickel) Our high-performance Free Nickel Nickel Electrolyte is preferably processed at room temperature (range from 15 to 60 °C). It is suitable for all common metals, semi-precious and precious metals with the exception of aluminum, chrome (dechrome beforehand) and titanium.   If you plan to nickel plate stainless steel yourself, please be sure to use a nickel strike for pretreatment or gold plate in advance with Goldflash. to increase adhesion.   Before galvanic nickel plating, clean the workpiece particularly thoroughly. Remove rust completely and degrease the component, e.g. with isopropanol. Be sure to work with clean disposable gloves to avoid transferring skin grease to the workpiece.   The nickel electrode from Betzmann Galvanik is particularly recommended - this results in a very high range, as the nickel is permanently enriched.   Please pay attention to the following recommendations, depending on the electroplating method used. Parameters: Bath electroplating: 2-5V (approx. 3V recommended at 10cm distance) Pin electroplating: 6-12V (approx. 8-9V recommended) Current density: 0.3-1.2A/dm² (up to 3A/dm² with bath movement) Working temperature: 15-60°C pH value: approx. 4 (can be corrected e.g. with 10% sulphuric acid) Deposition speed: approx. 0.3µm/min at 1A/dm² and 20°C   Identification of the mixture: Signal word: Caution Free nickel (contains nickel sulfate, nickel dichloride, nickel bis(sulfamidate), nickel di(acetate), diammonium nickel bis(sulfate)) GHS07 H317 May cause an allergic skin reaction. H412 Harmful to aquatic life with long lasting effects. P102 Keep out of the reach of children. P103 Read all instructions carefully and follow them. P261 Avoid breathing dust/vapor/aerosol. P280 Wear protective gloves and eye/face protection. P302+P352 IF ON SKIN: Wash with plenty of water. P333+P313 If skin irritation or rash occurs: Get medical advice/attention. P501 Do not dispose of contents/container with household waste and dispose of in accordance with regional/national regulations.

Graphite round rod - Graphite rod anode - Graphite electrode for gold plating.  Graphite electrodes are ultimate for all coatings. The advantage is that in some coatings with stainless steel electrodes, the dislodged metal parts disturb the coating. This does not happen with graphite electrodes, because graphite also filters out contaminated liquids. With bath electroplating, they also need to be replaced occasionally as they slowly dissolve during the plating process.   With pad electroplating, simply loosen the screw on the handle and replace with a new one.   Diameter 6 mm, length approx. 9 cm    Features Used for Doesn’t contaminate Cleaner Activating and electro-cleaning  Its resistive properties help to heat the solution you’re plating with Chromium plating, which needs to be plated at 25 degrees celsius; its natural heating action helps to maintain the solution’s optimal temperature Low cost Can be used for all plating processes but carbon electrodes deteriorate over a period of time and discolour swabs (discolouration does not affect the plating quality)
