Platinum Solution 6 G./Liter
€34.00
Available, delivery time: 1-2 days
Product information "Platinum Solution 6 G./Liter"
Platinum Electrolyte 6 g/L SW10033M
High-quality platinum plating solution for bright, wear-resistant platinum coatings
Short Description
The Platinum Electrolyte SW10033M is a ready-to-use electroplating solution for the electrolytic deposition of platinum coatings on conductive metal surfaces.
With a platinum content of approx. 6 g per liter, this electrolyte produces bright, light-gray, metallic platinum layers with excellent corrosion resistance, chemical stability, and wear resistance. Typical achievable layer thickness is up to 0.5–1.0 µm.
Platinum coatings are valued for their noble appearance and outstanding durability, making them suitable for decorative and functional applications.
Applications
The platinum electrolyte is suitable for:
-
Decorative surfaces with a bright, elegant platinum finish
-
Functional coatings requiring high corrosion and wear resistance
-
Electrical contacts and conductive components
-
Tank, brush, and pen/plug plating, depending on equipment
-
Applications requiring uniform, long-lasting platinum layers
It can be used in jewelry, design applications, and technical components alike.
How Platinum Plating Works (Simple Explanation)
Platinum plating is performed by electrolytic deposition:
-
Surface preparation: The workpiece is thoroughly cleaned and degreased.
-
Activation: If necessary, the surface is chemically activated to remove oxides.
-
Plating: By applying direct current, platinum ions are reduced from the electrolyte and deposited as a metallic platinum layer on the surface.
-
Finishing: After plating, the part is rinsed with clean water and dried, resulting in a uniform, bright metallic coating.
Benefits of Platinum Electrolyte SW10033M
-
Bright, light-gray metallic platinum finish
-
Excellent corrosion and chemical resistance
-
High wear resistance suitable for functional use
-
Cyanide-free, ready-to-use formulation
-
Suitable for tank, brush, and pen plating
-
Produces uniform coatings up to approx. 1 µm thickness
-
Reliable and stable process parameters
Technical Parameters
| Property | Value / Range |
|---|---|
| Electrolyte type | Platinum plating solution |
| Platinum content | approx. 6 g/L Pt |
| pH value | < 1 (strongly acidic) |
| Density | approx. 1.08 g/mL (increasing) |
| Operating temperature | 30–40 °C |
| Voltage | from 3 V |
| Plating time | approx. 2–4 minutes |
| Anode material | Platinized titanium |
| Anode/cathode area ratio | approx. 1 : 1 |
| Recommended movement | Bath or workpiece movement |
| Deposition rate | approx. 11 mg/A·min |
| Current density | approx. 0.5–1.5 A/dm² |
| Layer hardness | approx. 500 HV |
| Layer thickness | up to approx. 1.0 µm |
| Layer purity | 99.9 % Pt |
Values are practical guidelines and may vary depending on equipment and application.
Practical Application Tips
Preparation:
-
Clean and degrease parts thoroughly.
-
Activate chemically if necessary, especially on oxidized surfaces.
Plating:
-
Heat the electrolyte to 30–40 °C.
-
Apply voltage from 3 V and plate for 2–4 minutes.
-
Gentle bath or workpiece movement ensures even coating.
Post-treatment:
-
Rinse thoroughly with clean water after plating.
-
Dry completely; light polishing can enhance brightness if desired.
Safety Information
Platinum electrolytes are strongly acidic chemical solutions and must be handled with care:
-
Wear chemical-resistant gloves, safety goggles, and protective clothing
-
Avoid contact with skin and eyes
-
Rinse immediately with water in case of contact
-
Use only in well-ventilated areas
-
Do not ingest; keep out of reach of children
-
Dispose of waste according to local chemical regulations
Hazard statements typically include causes severe skin burns and serious eye damage.
Conclusion
The Platinum Electrolyte SW10033M is a reliable, professional-grade plating solution for producing bright, durable, and chemically resistant platinum coatings.
It is suitable for both decorative applications such as jewelry and accessories and technical or functional components. With stable process parameters, excellent layer quality, and versatile application methods, this electrolyte delivers uniform, long-lasting platinum finishes for workshops, laboratories, and professional plating operations.
Hazard statements
H314 Causes severe skin burns and eye damage.
Precautionary statements
P280 Wear protective gloves/protective clothing/eye protection/face protection.
P302 IF ON SKIN: P352 Wash with plenty of water.
P332 If skin irritation occurs:
P313 Get medical advice/attention.
P362 Take off contaminated clothing.
HS Code: 38249970
