White Palladium with 5 Gramm per Liter

Real Gold

€57.50*

Content: 0.05 Liter (€1,150.00* / 1 Liter)

(€48.32 ohne MwSt.)

Prices incl. VAT plus shipping costs

Available, delivery time: 1-2 days

50ml

100ml

250 ml

500 ml

1000 ml

2000 ml

Product number: SW10017

PDF offer

Create PDF offer for this product Tip: Add multiple products to the cart and create the offer there. Logged in users get an individualized offer.

Product information "White Palladium with 5 Gramm per Liter "

White palladium with 5 grams per liter - even brighter even more radiant as a nickel replacement - barrier layer or as a hard decorative top coat!

White Palladium Electrolyte - The allergen-free alternative to nickel!

White palladium electroplating or coating with palladium is a rather rarely used galvanic coating. However, white palladium plating can offer some advantages, especially as a substitute for electroplating nickel with a nickel electrolyte.

The advantages of white palladium electrolyte compared to electroless nickel plating:

Typically, a nickel electrolyte is used to apply a barrier layer of nickel between copper and gold, preventing the two metals from mixing. However, a palladium plating offers several distinct advantages over the nickel electrolyte:

White palladium is more noble than nickel, meaning no surface corrosion occurs, and the palladium does NOT require extra activation prior to gold plating as nickel does.

The deposition rate and efficiency are excellent, which means there is no unwanted gas evolution.

The electrolyte deposits bright silvery white, very light palladium which can be used as a bright "finish". Gold plating with the Betzmann gold electrolyte for pin electroplating achieves an optimum result on palladium.

White palladium, in contrast to nickel electrolyte, is not carcinogenic and is therefore also permitted for private users!

A very good combination for gold plating of almost all metals is:

Alkaline or acid copper depending on the metal, palladium and finally gold.

All necessary electrolytes are available in our store.

White palladium can be plated on the following metals:

Copper, nickel, brass, silver, gold, on all dechromed surfaces.

Recommended voltages: Pin electroplating: from 3 volts - Bath electroplating: 3 - 4 volts.

Recommended is graphite electrode or platinum electrode from our store.

Palladium content: 5 grams per liter

Main benefits;

Makes a great alternative to rhodium plating giving an authentic 18 carat white gold or platinum plated look.
palladium plating solution (unlike rhodium) doesn’t etch materials made of calcium carbonate such as pearl and coral, so you won’t have to worry about masking out these materials before submerging them in your palladium plating bath.
can be used as a substitute for nickel as a barrier layer for gold plating on copper and its alloys.
can be used as an alternative to silver as it doesn’t tarnish and is hard-wearing.
Very low porosity – excellent for corrosion protection.
Readily wettable by solder and dissolves a lot more slowly than gold in the solder making it an excellent top coat over gold for electrical contacts.

Operating Parameters and Deposit Data

Voltage Range	3.0 – 3.5
Temperature	18 – 25 °C
Palladium Concentration	5g/l
Electrode	Carbon or Platinum
Palladium content in plate	99.9% (balance carbon, nitrogen)
Lightness (L*) of deposit	65 (Cielab)
Plating Rate at (3.5 volts, carbon electrode)	0.6 micron per minute
Hardness	488 Hv
Density of deposit	11.85 g/cm3
Stress	Stressed
Special storage requirements	None
Shelf life	1 – 2 years
Health and Safety classification	Irritant
Special considerations	None
Transport (UN number)	None: Not classified as dangerous for transport

GHS07

Signalword: Warning

H-phrases:

H332 Harmful by inhalation.

H312 Harmful in contact with skin.

H302 Harmful if swallowed.

P phrases:

P280 Wear protective gloves/protective clothing/eye protection/face protection.

P301 IF INFECTED:P310 Immediately call a POISON CENTER/doctor/.
