Nickel Strike

Real Gold

€9.50*

Content: 0.1 Liter (€95.00* / 1 Liter)

(€7.98 ohne MwSt.)

Prices incl. VAT plus shipping costs

Available, delivery time: 1-2 days

100ml

250 ml

500 ml

1000 ml

2000 ml

5000 ml

Product number: SW10031

PDF offer

Create PDF offer for this product Tip: Add multiple products to the cart and create the offer there. Logged in users get an individualized offer.

Product information "Nickel Strike"

The new nickel strike from Betzmann Galvanik makes steels and stainless steels suitable for electroplating.

Nickel-strike or the so-called "nickel-on-nickel" was already used as an electrolyte in the 19th century. Today, nickel strike is indispensable in electroplating to prepare high-alloy stainless steels and steels for electroplating. This is because the oxides present on the surface of high-alloy metals impair the adhesive strength of the coating applied by means of bath electroplating or pin electroplating / pad electroplating. Therefore, the pretreatment with the impact nickel / nickel strike is necessary.

This is how the Nickel-Strike from Betzmann Galvanik works:

Pretreatment with Nickel-Strike prepares the surface for subsequent coatings. This is suitable for galvanic and electroless treatment. It etches the surface of the workpiece, dissolves contained chromium and creates a base layer of nickel in the course of this reaction. This micro-thin nickel layer of 0.5 - 1 µm now forms a reliably strong adhesive base for further coatings.

Ideally, you apply an intermediate layer after the treatment with impact nickel and before the final coating of the workpiece. This consists of copper or electroless or electroplated nickel. Whether the coating is applied by the bath electroplating or pin electroplating / pad electroplating processes is not relevant.

Areas of application for nickel strike

The nickel strike process covers a very wide range of applications. In addition to the pretreatment of high-alloy steels and stainless steels, a wide variety of non-ferrous metal alloys also require this pretreatment. These include, above all, alloys with silicon, magnesium, manganese, lead, tungsten or titanium.

Already nickel-plated objects that are exposed to air over a longer period of time lose the typical properties of the coating. These are then so-called passivated nickel layers, which a dip in Nickel-Strike reactivates.

Nickel-Strike for galvanic and electroless application

Nickel-strike is suitable for all electroplating processes from bath electroplating to pin electroplating / pad electroplating as well as for the electroless process.

Fields of application:

Stainless steel

Nickel

Before use:

Completely remove grease and oil especially thoroughly by using alcohol. Please remove dirt and rust with appropriate tools. Only handle the object with disposable gloves and in this way reliably prevent the transfer of skin grease to the surface.

Electroplating process (with power supply):

Anode bath electroplating: Graphite, nickel or platinum anodes.

Anode pin electroplating / pad electroplating: Graphite, nickel or platinum anodes, alternatively stainless steel anodes possible.

Parameters (these may vary, please test):

Bath electroplating: 1.5-4.5V (approx. 2.5-3V recommended at 10cm distance)

pin plating: 2,5-5V (approx. 3V recommended)

Current density: 8.5-25A/dm² (up to 50A/dm² with bath movement)

Working temperature: 20-50°C

Deposition rate: approx. 0.03µm/min at 10A/dm² and 20°C

pH value: 1

Attention:

for stainless steel: anode on positive pole - workpiece on negative pole

for nickel: anode on negative pole - workpiece on positive pole

Treat the workpiece with the pin plating or immersion process for about 10 to 60 seconds. Rinse the workpiece briefly afterwards. Immediately continue processing objects made of aluminum to prevent renewed oxidation.

Currentless process (without power supply):

Place the electrolyte in a suitable vessel and heat the impact nickel to a temperature of 35 - 50°C. Now place the object to be coated in the immersion bath for 0.5 - 3 minutes and finally rinse briefly. Please immerse aluminum objects at room temperature for a maximum of 0.5 - 1 minute!

Optionally, use the stop tickel tempered to room temperature. In this case, however, take into account the longer dwell time in the immersion bath.

To prevent renewed oxidation, objects treated with Nickelstrike should be further processed within 10 - 30 minutes. In the case of aluminum, immediate further processing is required.

Caution: Always use gloves and protective goggles and do not inhale the fumes / aerosols. Use only in well ventilated areas!

madeingermany-betzmann

Identification of the mixture:

Nickel Strike

(contains hydrochloric acid, nickel sulfamate, nickel diacetate, nickel dichloride, nickel(II) sulfate)

GHS05 GHS07

betzmann-galvanik-solution GHS07ENF5LtKTBYblK
Signal word: Danger

H290 May be corrosive to metals.

H314 Causes severe skin burns and eye damage.

H317 May cause an allergic skin reaction.

H335 May cause respiratory irritation.

P102 Keep out of the reach of children.

P103 Read all instructions carefully and follow them.

P260 Do not breathe dust/vapour/aerosol.

P280 Wear protective gloves and eye/face protection.

P301+P330+P331 IF INTOXICATED: Mouth off.

0 of 0 reviews

Leave a review!

Share your experiences with other customers.

Login

Your email address

Your password

No reviews found. Share your insights with others.

Similar Items

Palladium 2 Gramm / Liter

Palladium electrolyte with 2 Gram per Liter from Betzmann Galvanik - as nickel substitute - barrier layer or as hard decorative top layer! Palladium electrolyte - The allergen-free alternative to nickel! Palladinizing or plating with palladium is a rather rarely used galvanic coating. However, palladium plating can offer some advantages, especially as a substitute for galvanic nickel plating with a nickel electrolyte. The advantages of palladium electrolyte compared to electroless nickel plating: Typically, a nickel electrolyte is used to apply a barrier layer of nickel between copper and gold, preventing the two metals from mixing. However, a palladium plating offers several distinct advantages over the nickel electrolyte: Palladium is more noble than nickel, meaning there is no surface corrosion, and the palladium does NOT require extra activation prior to gold plating as nickel does. The deposition rate and efficiency are excellent, i.e. there is no unwanted gas evolution. The electrolyte deposits silvery white, very bright palladium which can be used as a bright "finish". Gold plating with the Betzmann gold electrolyte for pin electroplating achieves an optimum result on palladium. In contrast to nickel electrolyte, palladium is not carcinogenic and is therefore also permitted for private users! A very good combination for gold plating of almost all metals is: Alkaline or acid copper depending on the metal, palladium and finally gold. All necessary electrolytes are available in our store. Palladium can be plated on the following metals: Copper, nickel, brass, silver, gold, on all dechromed surfaces. Recommended voltages: Pin electroplating: from 3 volts - Bath electroplating: 3 - 4 volts. Recommended is graphite electrode or platinum electrode from our store. Palladium content: 2 grams per liter Main benefits; Makes a great alternative to rhodium plating giving an authentic 18 carat white gold or platinum plated look. palladium plating solution (unlike rhodium) doesn’t etch materials made of calcium carbonate such as pearl and coral, so you won’t have to worry about masking out these materials before submerging them in your palladium plating bath. can be used as a substitute for nickel as a barrier layer for gold plating on copper and its alloys. can be used as an alternative to silver as it doesn’t tarnish and is hard-wearing. Very low porosity – excellent for corrosion protection. Readily wettable by solder and dissolves a lot more slowly than gold in the solder making it an excellent top coat over gold for electrical contacts. Operating Parameters and Deposit Data Voltage Range 3.0 – 3.5 Temperature 18 – 25 °C Palladium Concentration 2g/l Electrode Carbon or Platinum Palladium content in plate 99.9% (balance carbon, nitrogen) Lightness (L*) of deposit 65 (Cielab) Plating Rate at (3.5 volts, carbon electrode) 0.6 micron per minute Hardness 488 Hv Density of deposit 11.85 g/cm3 Stress Stressed Special storage requirements None Shelf life 1 – 2 years Health and Safety classification Irritant Special considerations None Transport (UN number) None: Not classified as dangerous for transport Signalword: Warning H-phrases: H332 Harmful by inhalation. H312 Harmful in contact with skin. H302 Harmful if swallowed. P phrases: P280 Wear protective gloves/protective clothing/eye protection/face protection. P301 IF INFECTED:P310 Immediately call a POISON CENTER/doctor/.

Content: 0.05 Liter (€476.00* / 1 Liter)

€23.80*

Details

Conductive copper lacquer

Conductive copper lacquer from Betzmann Galvanik Real Gold Copper conductive lacquer from Betzmann Galvanik Product information copper conductive lacquer Article description: The copper conductive lacquer from Betzmann Galvanik at a glance: 50 or 200 ml copper conductive lacquer for electroplating for airbrush and brush non-conductive objects can be made conductive plants and natural objects can be electroplated easy and filigree application possible With the copper-based Galvano conductive lacquer from Betzmann Galvanik, you can coat works of art and gifts made of glass, ceramics, plastic and many other materials with a shiny layer of metal even in a short time. Perfect as an exclusive gift or for your own showcase! Also very suitable as a decorative varnish due to the strong gloss effect. Simply apply the copper conductive lacquer thinly with a brush on the cleaned surface. The copper conductive lacquer dries smudge-proof within 10 to 15 minutes and thus allows a quick processing of the workpieces. Complete drying for optimum hold on stressed surfaces takes approximately 12 - 36 hours at room temperature. The varnish can be thinned with butyl acetate or isopropanol. The next step is to connect the item with a wire and copperplate it in the acidic bright copper electrolyte from our store. A robust layer of copper will then be deposited. In the last step you can still nickel, silver and also gold or chrome plating the copper! Due to its lower price and high electrical and thermal conductivity, the copper conductive lacquer is thus the perfect alternative to silver conductive lacquer. Please note that copper plating must be carried out in the acidic copper electrolyte in the first step, as this activates the conductive lacquer. After copper plating, the metal layer is abrasion-resistant. Suitable materials: plastic, glass, ceramics, plants, wood and many other electrically non-conductive materials. Drying time: 5-15 minutes (smudge-proof), 1-3 days (complete for maximum demands) 20 mL is enough for an area of up to one square meter - so very productive!

Content: 0.05 Liter (€406.00* / 1 Liter)

€20.30*

Details

Anode sleeve fuzzy

Anode pad / tampon / anode sleeve / fuzzy sleeve / replacement fabric pad puffy from Betzmann Galvanik. This puffy fabric pad / anode sleeve or also called tampon is absolutely recommended for all plating processes. Optimally suitable for all coatings and electrolytes. The coating of larger areas is also quite fast with this pad. The insertion hole is larger than the electrode and therefore it happens that the moist anode pad slips off. Therefore, fix the pad on the electrode with a small rubber band.

€2.38*

Rust Remover

Rust Remover from Betzmann Galvanik! RUST REMOVER: Combined chemical agents and selected polishing clays result in a unique formulation for reviving heavily corroded metal objects. After removal, the natural protection of the metal is restored, corrosion inhibitors prevent attack on uncorroded parts. Ingredients: AQUA, ALUMINA, HYDROCHLORIC ACID, fatty alcohol polyglycol ether, fatty acids, 2-propyn-1-ol, compound with methyloxirane, XANTHAN GUM, COCAMIDOPROPYL BETAINE , prop-2-in-1-ol. Information on ingredients according to the Detergents Directive - Annex VII D, EC -648/2004 is available on the EU portal "European List of Cosmetic Ingredients". GHS05 GHS07 Danger. Causes severe skin burns and eye damage. May cause respiratory irritation. If medical advice is needed, have packaging or label at hand. Keep out of the reach of children. Wear protective gloves / protective clothing / eye protection / face protection. Do not breathe vapor. IF ON SKIN (or hair): Remove all contaminated, soaked clothing immediately. Wash skin with water/shower. IF IN EYES: Rinse cautiously with water for several minutes. Remove existing contact lenses if possible. Continue to rinse. Contains: Fatty alcohol polyglycol ether, hydrochloric acid.

Content: 0.1 Liter (€131.00* / 1 Liter)

€13.10*

Details

Nickel Electrode 6mm

Features "Nickel Electrode 6 mm from Betzmann Galvanik unalloyed rod anode made of pure nickel Ø 6 mm x 100 mm longer lengths on request as sacrificial anode for nickel plating by means of pin / tampon electroplating, reduced nickel electrolyte consumption, nickel layers are mainly used as diffusion barrier for gold plating of copper or as intermediate layer for tin plating Material sample with defined purity grade Ni 99.6 for comparative investigation of material properties Standard electrode for experiments in electrochemistry (electroplating, electrolysis, ion migration, determination of electrochemical potentials, conductivity titration, conductometric titration etc.) Material: nickel Degree of purity: 99.6 Diameter: 6 mm Length: 100 mm

€13.70*

Palladium 10 Gramm per Liter

Palladium Solution from Betzmann Galvanik with 10 Gramm per Liter - as nickel substitute - barrier layer or as hard decorative top layer! Palladium electrolyte - The allergen-free alternative to nickel! Palladinizing or plating with palladium is a rather rarely used galvanic coating. However, palladium plating can offer some advantages, especially as a substitute for galvanic nickel plating with a nickel electrolyte. The advantages of palladium electrolyte compared to electroless nickel plating: Typically, a nickel electrolyte is used to apply a barrier layer of nickel between copper and gold, preventing the two metals from mixing. However, a palladium plating offers several distinct advantages over the nickel electrolyte: Palladium is more noble than nickel, meaning there is no surface corrosion, and the palladium does NOT require extra activation prior to gold plating as nickel does. The deposition rate and efficiency are excellent, i.e. there is no unwanted gas evolution. The electrolyte deposits silvery white, very bright palladium which can be used as a bright "finish". Gold plating with the Betzmann gold electrolyte for pin electroplating achieves an optimum result on palladium. In contrast to nickel electrolyte, palladium is not carcinogenic and is therefore also permitted for private users! A very good combination for gold plating of almost all metals is: Alkaline or acid copper depending on the metal, palladium and finally gold. All necessary electrolytes are available in our store. Palladium can be plated on the following metals: Copper, nickel, brass, silver, gold, on all dechromed surfaces. Recommended voltages: Pen - Brush electroplating: from 3 volts - Bath electroplating: 3 - 4 volts. Recommended is graphite electrode or platinum electrode from our store. Palladium content: 10 grams per liter Main benefits; Makes a great alternative to rhodium plating giving an authentic 18 carat white gold or platinum plated look. palladium plating solution (unlike rhodium) doesn’t etch materials made of calcium carbonate such as pearl and coral, so you won’t have to worry about masking out these materials before submerging them in your palladium plating bath. can be used as a substitute for nickel as a barrier layer for gold plating on copper and its alloys. can be used as an alternative to silver as it doesn’t tarnish and is hard-wearing. Very low porosity – excellent for corrosion protection. Readily wettable by solder and dissolves a lot more slowly than gold in the solder making it an excellent top coat over gold for electrical contacts. Operating Parameters and Deposit Data Voltage Range 3.0 – 3.5 Temperature 18 – 25 °C Palladium Concentration 10g/l Electrode Carbon or Platinum Palladium content in plate 99.9% (balance carbon, nitrogen) Lightness (L*) of deposit 65 (Cielab) Plating Rate at (3.5 volts, carbon electrode) 0.6 micron per minute Hardness 488 Hv Density of deposit 11.85 g/cm3 Stress Stressed Special storage requirements None Shelf life 1 – 2 years Health and Safety classification Irritant Special considerations None Transport (UN number) None: Not classified as dangerous for transport Signalword: Warning H-phrases: H332 Harmful by inhalation. H312 Harmful in contact with skin. H302 Harmful if swallowed. P phrases: P280 Wear protective gloves/protective clothing/eye protection/face protection. P301 IF INFECTED:P310 Immediately call a POISON CENTER/doctor/. Operating Parameters and Deposit Data

Content: 0.05 Liter (€2,260.00* / 1 Liter)

€113.00*

Details

Nickelstripper

Nickel stripper strips nickel plating from steel, copper, brass and silver easily and delivers the following pluses; Ready-to-use solution: no need for mixing Low hazzard Stripping rates of up to 50 microns per hour at 62 °C High capacity (1 litre can strip 40 grams of nickel) Low odour: minimum ventilation needed Supplied as a one-component, ready-to-use solution Non-electrolytic stripper: no need for a separate rectifier Long bath life Can be shipped worldwide Operating Conditions Temperature Range 50 -65 °C (see notes) Tank Glass (see notes below), steel or polypropylene Agitation Mechanical (stirrer). Never use air agitation Stripping rate See notes below Stripping capacity Can strip up to 40 grams of nickel per litre Special storage requirements None Shelf life 1 – 2 years Health and Safety classification Irritant Special considerations None Transport (UN number) None: Not classified as dangerous for transport Notes: Tanks should be made of stainless steel, polypropylene or glass. If using glass,return the solution (cooled) to the container after use. Heating should be provided by a Teflon-coated stirring bar (if stripping in a beaker). For larger installations, stainless steel or titanium-sheaved heaters should be used. Stripping rates can be almost doubled by using light mechanical agitation: Stripping rate at 50°C = 10 microns per hour (no agitation) Stripping rate at 50°C = 17 microns per hour (with agitation) Stripping rate at 62°C = 50 microns per hour (with agitation) Black smut remaining can be removed by ultrasonic cleaning or scouring with pad. Nickelentferner GHS07 - Signal word: Caution H-phrases: H317: May cause an allergic skin reaction. P-phrases: P102: Keep out of the reach of children. P260: Do not breathe aerosol. P280: Wear protective gloves / eye protection. P302 + P352: IF ON SKIN: Wash with plenty of water. P501: Dispose of contents/container to hazardous waste.

Content: 0.25 Liter (€100.00* / 1 Liter)

€25.00*

Details

Nickel anode sheet

Nickel Bath Plate Electrode from Betzmann Galvanik Plate anode made of pure nickel for bath electroplating Sacrificial anode for galvanic nickel plating, nickel layers are mainly used as a diffusion barrier when gold plating copper or as an intermediate layer when tin plating pure nickel with a purity grade Ni 99,8% sheet thickness 0,5 mm available in sizes S (25 x 150 mm), M (50 x 80 mm), L (100 x 150 mm) and XL (170 x 200 mm) larger blanks as well as sheet thicknesses 1.0 and 1.5 mm on request material: nickel size: L - 100 x 150 mm, M - 50 x 80 mm, S - 25 x 150 mm, XL - 170 x 200 mm purity grade: 99,8

From €10.12*

Details
