Galvanic Unit - 40 Ampere

Connecting cable PLUS with banana plug:     Color RED  Length 1,50 meter For connection directly to the device      Color RED Length 1.50 meters For connection directly to the device incl. a stainless steel crocodile clip.     4mm banana plugs molded on both sides with strain relief and bend protection. Re-connectable - any number of plugs can be plugged into each other. Cylindrical contact spring for large area contact in the socket. Gold-plated contact surface for permanently low contact resistance. Fine stranded wire for highest flexibility and to avoid cable breakage. Conductor cross-section 1mm² - suitable for currents up to 25A. Double insulated cable with wear indicator by inner insulation in white -thereby damages at the insulation are immediately recognizable.   Pay attention to good quality for your electroplating and laboratory equipment! These cables have everything that is important for pleasant and durable use: large cross-section, good strain relief, gold-plated contacts and a flexible, yet resistant cable material with double insulation.

Anode pad / tampon / anode sleeve / fuzzy sleeve / replacement fabric pad puffy from Betzmann Galvanik.    This puffy fabric pad / anode sleeve or also called tampon is absolutely recommended for all plating processes. Optimally suitable for all coatings and electrolytes.  The coating of larger areas is also quite fast with this pad.   The insertion hole is larger than the electrode and therefore it happens that the moist  anode pad slips off. Therefore, fix the pad on the electrode with a small rubber band.

Electrode Handle: The electrode handle is is used to hold the various electrodes up to 6mm required throughout the plating process.The Electrode Handle will hold all of our rod-shaped electrodes including the stainless steel electrode, which should be used for chrome stripping and cleaning only, the carbon electrode which can be used for plating all metals and the platinum electrode which can also be used for plating all metals.

Connection cable MINUS with 2 banana plugs and a crocodile clip:   Color black  Length 1.50 meters For connection directly to the device incl. a crocodile clip.   4mm banana plugs molded on both sides with strain relief and bend protection. Re-connectable - any number of plugs can be plugged into each other. Cylindrical contact spring for large area contact in the socket. Gold-plated contact surface for permanently low contact resistance. Fine stranded wire for highest flexibility and to avoid cable breakage. Conductor cross-section 1mm² - suitable for currents up to 25A. Double insulated cable with wear indicator by inner insulation in white -thereby damages at the insulation are immediately recognizable.   Pay attention to good quality for your electroplating and laboratory equipment! These cables have everything that is important for pleasant and durable use: large cross-section, good strain relief, gold-plated contacts and a flexible, yet resistant cable material with double insulation.

Stainless steel electrode 6 mm This electrode is ideal for most work steps. It can mainly be used for degreasing, activating, and dechroming, and is also very good for chromium plating.Important! Stainless steel electrodes can cause contamination of the coating solution in other coating processes. In this case, it is recommended to use a more suitable anode, e.g., made of graphite or platinum. Stainless steel electrodes and, ideally, aluminum electrodes are suitable for chromium plating. Graphite or platinum electrodes are suitable for gold plating. Graphite or silver electrodes are suitable for silver plating. Length: 9.5 cm, diameter 6 mm

Betzmann Galvanik Pen Electroplating Pen - Product features at a glance: Our Galvanic Pen - Electroplating Pen consists of a graphite core that is ultimate for all coatings.       The pen for the finest and most delicate pen electroplating with graphite electrode. + 3 x felt tips + 2 x cable + alligator clip Suitable for plating most metals ideally suited for our BMG-25A and 50A electroplating systems.   The electroplating pens offer among others jewelers, watchmakers, jewelry manufacturers and also and also to all hobby electroplaters the possibility to galvanically refine pieces of jewelry in a simple way. The electroplating pens make it possible to carry out fine and very fine decorative electroplating work on jewelry and other small parts. In this way, jewelry can even be partially gold-plated. With the pen electroplating system it is possible to do a 2-tone precious metal coating even on very small surfaces. Whether in the studio, in the jewelry industry jewelers: the electroplating pens with the fine fiber pen attachments enable multifaceted color shades and sophisticated sophisticated results that will amaze you. The electroplating pens are also ideal for repair and touch-up work.  Electroplating Pens are ideally suited.   Directions for use: The plus cable is plugged in at the end of the grip piece, and a replaceable felt in the front. Please use one felt per electrolyte (they can be used for a very long time). The felts should be thoroughly soaked and moistened before use, as this is the only way they will pass the current.   The integrated graphite electrode is excellent for gold plating, chrome plating, silver plating, palladium plating, copper plating, zinc plating, black ruthenium, black chrome, black rhodium Nickel plating, rose gold, green gold, white gold and more.    Guide you will get when you buy the product.
