Tin
€15.47
Available, delivery time: 1-2 days
Product information "Tin"
Tin Solution - Tin Electrolyte - self tinning from Betzmann Galvanik
Our versatile tin plating solution is used in applications ranging from the cookware industry to high-end electronics.
Recommended electrode: platinum electrode or graphite electrode
From 3 volts
Can be plated on copper, nickel or thin gold layer
Please note: This is an air sensitive solution. When not using the solution, keep the lid tightly closed and take steps to minimize air space in the bottle.
You can do this by adding marbles or glass beads to the bottle, squeezing out the excess air at the top of the bottle, or drawing up the solution and storing it in one of our storage syringes.
Failure to follow the above precautions may result in degeneration of the tin in the solution.
Operating Conditions and Deposit Data
| Plating Factor | 0.01 A/cm2 (see notes) |
| Plating rate | ~0.5 micron per minute at 0.01A/cm2, 20°C with mild agitation |
| Maximum plating thickness | In excess of 1000 microns (1mm) |
| Temperature | 18 – 25 |
| pH | 3.6 – 4.0 |
| Tin concentration | 22 grams per litre |
| Filtration | Continuous through filter pump especiall if anode bags not used. |
| Visual qualities of deposit | Matt to satin finish turning crystaline at thickensses greater than 20 microns |
| Agitation | Medium to vigorous |
| Electrode | Tin |
| Tin content in plate | 99.9% (balance carbon) |
| Cathode efficiency | 100% at Plating Factor = 0.01A/cm2 with mild agitation. |
| Hardness | 1.5 (Mohs Hardness) |
| Density of deposit | White (β): 7.289 g/cm |
| Stress | Low – undetectable |
| Special storage requirements | Store in hermetically sealed container as the tin salt is oxygen sensitive. |
| Shelf life | 1 – 2 years |
| Health and Safety classification | Irritant |
| Special considerations | None. |
| Transport (UN number) | None: Not classified as dangerous for transport |
Notes:
- Higher plating factors can be used and/or anodes used for longer if anode
bags are not used. However continuous filtration wll be necessary.
.gif?ts=1720611308)
Labelling according Regulation (EC) No 1272/2008
Pictogram Signal word Warning Hazard statement(s).
H316 Causes mild skin irritation.
H320 Causes eye irritation.
H335 May cause respiratory irritation.
P261 Avoid breathing dust/ fume/ gas/ mist/ vapours/spray.
P305 + P351 + P338 IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.
